High-frequency electrosurgical unit designed for precision surgery and microsurgery, both monopolar and bipolar, without tissue alterations. It allows surgical treatments with programmable operating times in milliseconds or in traditional mode. MB FLASH offers several operating modes: pure cutting CUT, cutting-coagulation BLEND, incisions with reduced ENHANCED carbonization, superficial coagulation FORCED COAG, deep coagulation without necrosis SOFT COAG and bipolar coagulation BIPOLAR COAG.

The digital reading of the power output and the monitoring of the operating functions by means of a microcontroller guarantee the reliability of the working conditions. The connection of the neutral electrode is constantly monitored and the safety of the plate/patient contact is controlled by a bipartite neutral electrode. The functions and power delivery can be controlled from the electrode holder handpiece, allowing you to operate without diverting your attention from the operating field.

Technical features:
- Plate-patient contact control
- Use of bipartite neutral electrode
- Minimally invasive surgical treatment
- Independent monopolar and bipolar functions
- Automatic start/stop in bipolar coagulation
- Planning of working conditions
- Power delivery with pedal and/or handpiece
- Digital power control and indication
- Adjustment of the intensity of the sound emission
- Adjustable power boost
- Emission time setting and RF power pulse interval

Specifications:
- Max CUT Power: 120W-250Ohm
- Max BLEND power: 90 W-200 Ohm
- Max ENHANCED power: 90W-250 Ohm
- Max power FORCED COAG: 80 W-150 Ohm
- Max power SOFT COAG: 60 W-100 Ohm
- BIPOLAR COAG max power: 60 W-50 Ohm
- Working frequency: 600 kHz
- RF power pulse emission time: 10ms - 30sec
- RF power pulse range: 1 - 9
- Patient circuit: F
- Selectable input voltage: 115 - 230 Vac
- Mains frequency: 50 - 60 Hz
- Maximum power consumption: 350 VA
- Dimensions WxHxD: 370 x 144 x 319 mm
- Weight: 6 kg
- Controls: Plate/patient circuit control, Output power control, Self-diagnosis
- Safety: EN60601-1, EN60601-1-2, EN60601-2-2, Electrical class: I CF, DDM 93/42/EC Class: II b

Equipment:
- MB two-button sterilizable handpiece (30536)
- Flexible steel neutral plate with cable (30555-30560)
- MB Waterproof Pedal (30577)
- Kit of 10 standard short electrodes Ø 2.4 mm
- 3 needle electrodes + 3 blade electrodes + 3 ball electrodes 7 cm
- 2 disposable plates (30562)
- 5m power cable
- Microsurgery Handpiece (30552)
- Microsurgery needles 10 pcs.
- Manual: GB, IT
