New-generation electrosurgical units that allow two surgeons to work simultaneously.

The radiofrequency generator is suitable for microsurgery and precision surgery in monopolar and bipolar modes.

Its simplicity allows it to be used without prior training, saving time as a result.
The initial configuration and adjustment of settings during surgery can be easily selected using the large touchscreen.

Performance, usability, design and reliability
- simultaneous activation of monopolar and bipolar modes
- impedance-based power control
- power activation by footswitch and/or handpiece
- neutral electrode-patient contact monitoring
- cutting function under saline solution TUR
- modular cutting in moist conditions BLEND
- blood vessel sealing to close blood vessels up to 7 mm
- minimally invasive surgical treatment
- monopolar/bipolar functions
- automatic start/stop in bipolar mode
- sound emission intensity adjustment

An intuitive and logical working environment
A particularly simple and intuitive working environment.
The horizontal alignment of the monitors, RGB indicator lights and connectors provides a clear, easily readable overview.
The large 9” capacitive touchscreen, with its elegant flat design, ensures faster and more efficient cleaning in the operating room.

State-of-the-art device
Highly professional surgery with ergonomic and safe solutions.
The neutral electrode connection is constantly monitored: if a bipartite neutral plate is used, the device monitors the contact between the patient and the electrode.
The ability to switch functions and activate power delivery from the handpiece makes it possible to perform surgical procedures without taking attention away from the surgical field.

Software
Developed to provide a simple, functional and intuitive working experience. With a single touch, you can customise and save working settings, adjust cutting or coagulation power, and manage every device function.

Recommended for: GASTROENTEROLOGY, GENERAL SURGERY, NEUROSURGERY, ORTHOPAEDICS, PAEDIATRIC SURGERY, PLASTIC SURGERY, THORACIC SURGERY, TRANSURETHRAL RESECTION (TUR), UROLOGY

Can be used for: DERMATOLOGY, ENDOSCOPY, GYNAECOLOGY, OTORHINOLARYNGOLOGY, PNEUMOLOGY, VASCULAR SURGERY, VETERINARY MEDICINE

Made in Italy.

1 piece.

Max. PURE CUT power: 400 W - 300 Ohm
Max. BLEND power: 250 W - 300 Ohm
Max. ENHANCED power: 250 W - 300 Ohm
Max. FORCED COAG power: 150 W - 150 Ohm
Max. Soft COAG power: 150 W - 200 Ohm
Max. FULGURATION power: 100 W - 500 Ohm
Max. BIPOLAR TUR power: 300 W - 200 Ohm
Max. BIPOLAR CUT power: 150 W - 100 Ohm
Max. BIPOLAR COAG power: 150 W - 50 Ohm
Max. BIPOLAR SEALING power: 250 W - 50 Ohm
Operating frequency: 360 kHz
Patient circuit: F
Selectable input voltage: 100-240 Vac
Mains frequency: 50-60 Hz
Maximum power consumption: 1000 VA
Dimensions LxHxD: 450 x 200 x 420 mm
Weight: 15.5 kg
Controls: Neutral plate/patient circuit monitoring, Output power monitoring, Self-diagnostics, HF leakage current monitoring, Mains fluctuation compensation
Safety: EN60601-1, EN60601-1-2, EN60601-2-2, Electrical class: I CF, MDD 93/42/CEE Class: II b

Flexible stainless-steel neutral plate with cable (30556+30560)
Power cable 5 m
Reusable handpiece with switches (30536)
Waterproof MB footswitch (30608)
3 blade electrodes - 16 cm
3 blade electrodes - 7 cm
3 ball electrodes Ø 4 - 6 cm
