DIATERMO MB 200 TOUCH - 200W

High-frequency electrosurgical unit suitable for monopolar and bipolar precision surgery and microsurgery without tissue alterations.
It can provide high-frequency operating power even for short times of up to hundredths of a second.
The unit allows pure CUT cutting, BLEND cutting-coagulation, incisions with reduced ENHANCED carbonization production, FORCED COAG surface coagulation, SOFT COAG depth coagulation in the absence of necrosis, BIPOLAR CUT, BIPOLAR COAG and BIPOLAR SEALING cutting, coagulation and sealing, and finally FULGURATION electrocution.

The digital reading of the power output and the monitoring of the operating functions by means of a microcontroller ensure the absolute reliability of the working conditions.
Diatermo MB 200 Touch allows highly professional surgery thanks to the ergonomic and safety solutions adopted.

The connection of the neutral electrode and the safety of the plate/patient contact are constantly monitored. The possibility of controlling the functions and power delivery from the electrode handpiece allows the execution of surgical interventions without diverting attention from the operating field.

Software
Developed to provide a simple, functional and intuitive working experience. With a single touch of a finger you can customize the screen and work settings, change the power of cutting or coagulation and manage every function of the device.

Recommended for: EMERGENCY ROOM / NEUROSURGERY / PULMONOLOGY / ENDOSCOPY / FIRST AID / OTORHINOLARYNGOLOGIST / UROLOGY / GASTROENTEROLOGY / VASCULAR SURGERY / VETERINARY / GYNECOLOGY

Can be used for: ORTHOPEDICS / TUR TRANSURETHRAL RESECTION / PEDIATRIC SURGERY / GENERAL SURGERY / PLASTIC SURGERY

Made in Italy.

1 pc.

Max power:
PURE CUT: 200 W - 300 Ohm
BLEND: 150 W - 300 Ohm
ENHANCED: 150 W - 300 Ohm
FORCED COAG: 150 W - 200 Ohm
SOFT COAG: 100 W - 200 Ohm
FULGURATION: 100 W - 1000 Ohm
BIPOLAR SEALING: 200 W - 50 Ohm
BIPOLAR COAG: 120 W - 50 Ohm
BIPOLAR CUT: 120 W - 50 Ohm

RF power pulse emission time: 10 ms - 30 sec
RF Power Pulse Range: 1 - 30
Patient circuit: F
Selectable input voltage: 100 - 240 VAC
Network frequency: 360KHz
Maximum power consumption: 750 VA
Dimensions (WxHxD) - Weight: 370 x 145 x 300 mm - 6 kg
Controls: Plate/patient circuit control, power output control, self-diagnosis
Safety: EN60601-1, EN60601-1-2, EN60601-2-2
Electrical classification: I CF DDM 93/42 / CE: Class II b

Flexible steel neutral plate with cable (30555+30560)
Kit of 10 standard short electrodes Ø 2.4 mm (30500)
Power cable 5 m
Handpiece and electrode container
Reusable Handpiece with Switches (30536)
Waterproof Pedal (30577)
