DIATERMO MB 160D - mono-bipolar - 160 Watt

Diatermo MB-D is a high-frequency electronic electrosurgical unit suitable for minor and medium-sized surgical procedures.

By selecting the functions it allows you to perform pure cutting (CUT), coagulated cutting (BLEND), superficial coagulation (FORCED COAG), deep coagulation in the absence of carbonization (SOFT COAG) and, with the appropriate adapter, bipolar coagulation (BIPOLAR).

Digital reading of the power output and microcontroller monitoring of the operating functions help create the best conditions for intervention.

Diatermo MB-D allows for highly professional surgery thanks to its ergonomic and safety solutions. The electrosurgical unit is equipped with a system to monitor the correct functioning of the neutral electrode.

Possibility of switching functions and controlling power delivery from the electrode holder handpiece, allowing surgical interventions to be performed without diverting attention from the operating field.

Characteristics:
- minimally invasive surgery
- possibility of using bipolar forceps
- possibility of using split neutral electrodes
- saving the last settings used
- power activation with pedal and/or handpiece
- digital power regulation and indication
- adjustment of the intensity of the sound emission

Made in Italy.

1 pc.

- Max cutting power CUT: 160 W - 250 Ohm
- Max cutting-coagulation power BLEND: 120 W - 200 Ohm
- Max coagulation power FORCED COAG: 100 W - 150 Ohm
- Max coagulation power SOFT COAG: 80 W - 100 Ohm
- Maximum bipolar power BIPOLAR: 60 W - 100 Ohm
- Working frequency: 600 kHz
- Neutral electrode: F
- Selectable power supply: 115 - 230 Vac
- Mains frequency: 50 - 60 Hz
- Maximum power consumption: 350 VA
- Dimensions WxHxD mm: 254 x 104 x 288
- Weight: 5 kgs
- Controls: Plate/patient circuit control, power output control, self-diagnosis
- Safety: EN60601-1, EN60601-1-2, EN60601-2-2,
- Electrical classification: I CF; MDD 93/42/EC Class: II b

- Disposable MB handpiece with 2 buttons
- Waterproof operating pedal 30577 (alternative to the use of the handpiece)
- Flat plate with cable 30564
- Kit of 10 autoclavable electrodes, Ø 2.4 mm
- 2m power cable
- User manual: GB, IT, available on request in FR, ES, PL.
