The NeoECG T180 12-lead ECG tablet with Glasgow interpretation and printer from Lepu Medical is an advanced, portable electrocardiographic device designed for the professional acquisition, display, and management of ECG waveforms in clinical settings. Its compact design and integrated technology make it an ideal solution for healthcare facilities requiring mobility, diagnostic accuracy, and connectivity.

Equipped with a 10.1” high-resolution color touch screen , the device allows intuitive interaction and clear display of synchronously acquired 9- or 12-lead ECG waveforms. The integrated Glasgow interpretation algorithm ensures accurate automatic analysis, supporting healthcare professionals in cardiac diagnosis.

The system offers four sampling modes (pre-sampling, real-time, periodic, trigger), automatic pacemaker detection , and advanced features such as RR , HRV , drug testing , and ECG event mode . The waveform can be frozen on the screen for detailed review, while the virtual keyboard and barcode scanner simplify patient data entry.

ECG data can be stored, reviewed, edited, and transmitted via Wi-Fi or mobile network , with the option of exporting to a USB flash drive . Files can be saved in various formats: Carewell ECG, PDF, BMP, HL7, DICOM, and SCP.

The device integrates a high-performance thermal printer with selectable speeds (5, 6.25, 10, 12.5, 25, 50 mm/s, error < ±3%) and adjustable sensitivity (auto, 2.5, 5, 10, 20, 40 mm/mV, error < ±5%).

Main technical specifications:

• Heart rate: 30–300 bpm ±1
• A/D resolution: 24 bit
• Sampling rate: 32,000 samples/sec
• Filters: AC (50–60 Hz), EMG (25–45 Hz), ADS (0.01–0.67 Hz), lowpass (75–300 Hz)
• Frequency response: 0.01–350 Hz (+0.4–3.0 dB)
• Minimum detectable signal: 20 µVp-p
• Internal noise: ≤12.5 µV
• Input impedance: ≥100 MΩ (10 Hz)
• Input circuit current: ≤10 nA
• Calibration voltage: 1 mV ±2%
• Depolarization voltage: ±900 mV ±5%
• Common Mode Rejection: ≥140 dB (AC filter on), ≥120 dB (AC filter off)
• Amplitude quantization: 0.95 µV/LSB
• Recovery time on discharge: <10 s

The NeoECG T180 is powered by an external DC power supply and a built-in rechargeable lithium battery . It includes a recorder charging port and selectable multilingual software (GB, FR, IT, ES, PT, DE, GR, PL).

Dimensions and weight: 27.4 x 28.8 xh 11.1 cm – 2.5 kg

Standard equipment:

• 1 ECG cable (IEC, Ø 4 mm, banana plug)
• 6 adult suction cup chest electrodes (Ø 4 mm)
• 4 clamp electrodes for limbs (arms/legs)
• 1 roll of thermal paper (20 m x 216 mm)
• 1 rechargeable lithium battery
• 1 power adapter
• Multilingual manual (GB, IT; on request: FR, ES, PT, DE, GR, PL)

The NeoECG T180 ECG Tablet is the ideal choice for clinics, outpatient clinics and hospital departments that require a professional, reliable and easily portable ECG, with advanced features and full compatibility with the main healthcare interoperability standards.
