CardioPocket ECG 3 channels with software
ECG CARDIOPOCKET with 3 channels and integrated software. This 12-lead electrocardiograph uses a thermal system to print ECG waveforms and offers automatic measurement and diagnosis of ECG parameters.
- Secure payments: credit card, Paypal and bank transfer
- Fast shipping: Poste Delivery Express, FedEx, UPS
- Customer support Whatsapp +39 371 43 61 201
ECG CARDIOPOCKET with 3 channels and integrated software. This 12-lead electrocardiograph uses a thermal system to print ECG waveforms and offers automatic measurement and diagnosis of ECG parameters.
Main functions:
- Fully automatic analysis with auto-analysis and self-diagnosis for routine ECG parameters
- Provides measurement results and self-diagnosis conclusions for HR, P-R interval, P duration, QRS duration, Q-T interval, Q-tc, P axis, QRS axis, T axis, R(V5), S(V1), R(V5)+S(V1)
- 2.83" LCD color display (320x240), usable as a touchscreen or with the keyboard
- High-resolution thermal output system 8 dots/mm (vertical)
- Removable, rechargeable lithium battery with an operating time of 4 hours and printing capacity of up to 90 minutes and 150 ECGs
- Memory for 100 cases on SD card
- Digital filter to eliminate baseline distortion
- ECG synchronization software to create an ECG workstation
Technical specifications:
- Dimensions: 207 x 96 x 62 mm
- Net weight: 500 g
- Power supply: AC 100-240 V, 50/60 Hz - DC 12V, rechargeable lithium battery 2000 mAh
- Noise level: ≤15 µVp-p
- CMRR: >60 dB, >100 dB (with additional filter)
- EMG filter: 25/35 Hz
- Time constant: ≤3.2 s
- Frequency response: 0.05-150 Hz (-3 dB - 0.4 dB)
- Patient leakage current: <10 µA
- Paper recording: 50 mm x 20 m, high-speed thermal paper
- Paper speed: 6.25, 12.5, 25, 50 mm/s ±5%
- Safety standard: IEC Class I, defibrillation-proof type CF
- Input mode: protection against fluctuation and defibrillation
- Input circuit current: ≤0.1 µA
- Input impedance: ≥50 MΩ
Supplied with:
- Patient cable
- 1 roll of paper
- 1 rechargeable lithium battery
- 4 limb electrodes
- 6 precordial electrodes
- 1 user manual (GB, IT, FR)
- 1 software CD (GB, FR, IT, ES, DE, TR) and cable for connection to PC
Attachments
Catalog page
Declaration of Conformity (EN)
Manuale d'uso (IT)
User Manual (EN)
Manuel d'utilisation (FR)
Manual de uso (ES)
