Pocket spirometer MIR Spirobank 2 Basic with software MIR Spiro

Spirobank 2 Basic is a simplified and accurate spirometer, ideal for respiratory disease specialists, general practitioners, clinics and pharmacies. It can operate independently or be connected to a PC via a USB cable.

Spirometry parameters:
- FVC
- FEV1
- FEV1%
- PEF
- FEF25–75
- FET
- Extrapolated Volume
- Lung Age
- VC
- IVC
- IC
- ERV
- PRE- and POST-bronchodilator comparison

Available with a reusable turbine flow meter (optional) or a disposable one.

Automatic spirometry interpretation:
- Internal temperature sensor for BTPS conversion
- High-resolution backlit display
- Traffic-light indicator for immediate interpretation
- Memory capacity for over 10000 spirometry tests
- Rechargeable battery with long battery life

USB connectivity:
- Real-time testing on a PC via USB

WinspiroPRO PC software:
- Real-time Flow/Volume and Volume/Time curves
- PRE/POST bronchodilator comparison
- Free online updates

Includes a pediatric incentive for spirometry and reversibility analysis after bronchodilator administration and bronchial provocation. Supports Quanjer GLI-2012 predicted values with LLN and Z-score, and provides diagnostic trend graphs for easy follow-up.

Search engine for immediate access to the database and a wide selection of communication protocols.

Technical specifications:
- Dimensions: 55 x 160 x 25 mm
- Weight: 140 g (batteries included)

Turbine:
- For use only with the FlowMIR disposable turbine (code 910004)

Battery:
- Rechargeable lithium-ion, 3.7 V, 1100 mAh
- Consumption: ~20-30 mA (during testing)

Battery charger:
- Voltage: 5 V DC
- Current: minimum 500 mA
- Input current: 100 VAC - 240 VAC
- Connector: type B micro USB
- Complies with standard EN 60601-1

Other features:
- Battery life: 50 hours
- Connectivity: USB 2.0
- Display: monochrome LCD, 160 x 80 pixels
- Keyboard: membrane with 6 keys
- Mouthpiece: Ø 30 mm (1.18 inches)
- Type of electrical protection: Internally powered
- Safety level: Type BF equipment
- IP protection rating: IPX1
- Operating conditions: Equipment for continuous use

Storage conditions:
- Temperature: MIN -20 °C, MAX +60 °C
- Humidity: MIN 10% RH, MAX 95% RH

Operating conditions:
- Temperature: MIN +10 °C, MAX +40 °C
- Humidity: MIN 10% RH, MAX 95% RH

Spirometry:
- Sensor: bidirectional digital turbine
- Flow range: ±16L/s
- Volume accuracy: ±2.5% or 50mL
- Flow accuracy: ±5% or 200 ml/s
- Dynamic resistance: <0.5 cm H2O/L/s
- Temperature sensor: semiconductor (0-45°C)
- Available tests: FVC, VC, IVC, POST
- Measured parameters: FVC, VC, IVC, IC, ERV, FEV1, FEV1%, PEF, FEF 25-75, FET, EVOL, ELA
- Memory capacity: more than 10000 tests

Certificates and registrations:
- CE 0476: MDR 2017/745
- FDA 510 (k): K 061712
- Health Canada: 71191 (Class II)
- EMDN Level 4: Z121501
- CND code: Z12150102 (spirometer)
- GMDN code: 46906 (spirometer)
- Registry number: 2494320/R (911021I0)

Applicable standards:
- Electrical safety standard IEC 60601-1:2005 +Amd1:2012
- Electromagnetic compatibility standard EN 60601-1-2:2015
- ISO 26782:2009
- ISO 23747:2015
- ATS/ERS: 2005, 2019 Update

Included:
- MIR Spirobank 2 Basic spirometer
- Carrying case
- USB cable
- MIR Spiro software
