The Volumetric Infusion Pump B. BRAUN Space Plus Infusomat is an advanced solution for administering small volumes of medication, infusion solutions and nutritional solutions. This portable peristaltic device complies with safety standards IEC/EN 60601-1 and IEC/EN 60601-2-24, ensuring reliability and safety. It can be used on its own or integrated into the B. BRAUN Space system for centralized management of infusion therapies.

Advantages:
- Intuitive, standardized user interface
- Automatic calculation of the infusion rate
- Automatic calculation of the administration rate
- Battery life: approximately 11 hours with WiFi on, 13 hours with WiFi off

Drug Library:
- Storage of up to 10000 medications in 30 categories
- Specific infusion limits for each medication

Safety features:
- Integrated safety device against free flow
- Automatic reduction of the bolus in the event of an occlusion
- Data lock with 3 security levels
- Alarm with error messages on the display

Risk Class: IIb

Caution: the package does not include the power supply.

Spike:
- Dual channel for liquids and air
- Spaced air and liquid openings
- Smooth surface
- Calibrated for 20 drops/ml

Drip chamber:
- High transparency
- Large and squeezable
- Particle-retention filter of 15 mm

Central ring:
- Facilitates piercing
- Anchor point for the drip sensor

Air inlet valve:
- Pressure compensation
- Hydrophobic antibacterial filter

Tubing (Infusomat Standard Set):
- Internal diameter: 3.0 mm
- External diameter: 4.1 mm
- Bolus volume: 3.0 ml/m at 40°C and 2 bar
- Total length 250 cm, pump-to-patient section 145 cm
- High transparency

Precision roller clamp:
- Ergonomic
- Knurled roller
- Positioning hook
- Spike holder for disposal

Pump segment:
- Compatible with the pump's peristaltic action
- Internal diameter: 4.0 mm
- External diameter: 6.0 mm
- Highly resistant and non-deformable
