Nellcor handheld pulse oximeter PM10N with reusable sensor DS100A

The Nellcor PM10N handheld pulse oximeter with reusable DS100A sensor is a portable, lightweight and ergonomic device designed for non-invasive monitoring of functional arterial hemoglobin oxygen saturation (SpO₂), pulse rate and pulse amplitude. It is indicated for use in adult, pediatric and neonatal patients, for both continuous monitoring and Spot checks, in hospitals, at home and during transfers.

The system uses OxiMax technology, which ensures high performance even in conditions of low peripheral perfusion and in the presence of patient movement.

Main features:
- 88.9 mm color LCD screen (diagonal)
- Numerical display of SpO₂ and pulse rate, plethysmographic waveform
- Selectable patient modes: adult or neonatal
- Operating modes: Sleep Mode and Home Care
- SatSeconds alarm management system to reduce false alarms caused by transient desaturations
- Fully configurable audible and visual alarms
- Trend memory: 80 hours, downloadable to a PC via HyperTerminal or NAT software
- Power supply: 4 AA lithium batteries, 1.5 V each, with a battery life of up to 20 hours
- User interface with multifunction push buttons
- Error messages displayed in the event of a fault

SpO₂ measurement accuracy:
- Adults/neonates 70%-100%: ±2%
- Low Sat (60%-80%): ±3%
- Low perfusion: 70%-100%: ±2%
- With movement: 70%-100%: ±3%

Pulse rate:
- Adults/neonates: 20–250 bpm ±3 bpm
- Low perfusion: 20–250 bpm ±3 bpm

Technical specifications:
- Dimensions: 7 x 15,6 x 3,2 cm
- Weight: 274 g (batteries included)
- IP22 protection rating against liquid ingress
- Operating temperature: from 5°C to 40°C
- Storage temperature: from -20°C to 70°C
- Operating humidity: 15%–95% (non-condensing)
- Operating altitude: from -390 to 5574 m

Compatibility and accessories:
- Compatible with DEC4 cable (optional)
- Compatible with NAT software for data download

Warnings: Do not use during Magnetic Resonance Imaging examinations to avoid the risk of burns and interference with diagnostic images. Do not modify the device and do not use it if damaged. Do not immerse in water or cleaning solutions.

Note: The release of the new version of NAT software compliant with the European GDPR is scheduled for the first few months of 2025; temporary difficulties downloading the application may occur.

Contents:
- 1 Nellcor PM10N handheld pulse oximeter
- Reusable DS100A sensor
- 4 AA-type lithium batteries, 1.5 V
- 1 CD and/or operator's manual
- Home care user guide
