Spirodoc is easily customizable for different uses:
- with advanced parameters for the specialist
- with simplified functions for the GP and the pediatrician with essential reports for an initial screening
- with easy-to-use functions for patient monitoring at home

All parameters are displayed directly on the screen.

Suitable for telemedicine projects with remote diagnosis via web and Bluetooth connection

Spirodoc won the prestigious international design award “reddot” 2010.

6-Minute Walk Test:
Spirodoc is the only device on the market that uses the 6-minute walk test to estimate the amount of oxygen needed (O2 Gap index) to compensate for exercise desaturation. This index is a great aid in prescribing.

The first "3D Oximeter":
The most recent clinical studies have shown that physical activity is closely related to life expectancy. Even chronically ill patients should continue to engage in regular physical activity. Spirodoc highlights the relationship between desaturation events and patient activity (pedometer, movement analysis, VMU).

Sleep oximetry:
Sleep desaturation analysis with event storage and automatic body position detection thanks to the three-dimensional accelerometer.

MIR Spiro Software
- Complete software for Spirometry and Oximetry
- Designed to be integrated with EMR/EHR
- Complies with the latest ATS/ERS guidelines
- Available for desktop, laptop and tablet (MIR Spiro App)
- Compatible with MacOS, Windows, iOS and Android

All MIR professional devices work with MIR Spiro software, the latest generation software for Spirometry and Oximetry.

CENTRAL UNIT:
- Display: Backlit touchscreen LCD, 128x64 pixel resolution
- Power supply: 3.7V, 1100mA rechargeable lithium-ion battery
- Data transmission: USB 2.0 On-The-Go and Bluetooth 2.1
- Accelerometer: triaxial ±2g, 400Hz
- Dimensions and Weight: Machine body 101x48x16mm, 99g; Turbine holder 46x47x24mm, 17g
- Battery charger (opt.): Input 100VAC - 240VAC, 50Hz-60Hz; Output 5VDC, 500mA, micro USB type B

Pulse Oximeter:
- SpO2 measurement: 0-99%
- SpO2 accuracy: ±2% between 70-99%SpO2
- Pulse rate measurement: 30-254BPM
- Pulse rate accuracy: ±2BPM or 2%, whichever is greater

Basic pulse oximetry parameters:
SpO2 [Baseline, Min, Max, Average], Pulse Rate [Baseline, Min, Max, Average], T90% [SpO2<90%], T89% [SpO2<89%], T88% [SpO2<88%], T5 [ΔSpO2>5%], ΔIndex [12s], SpO2 Events, Pulse Rate Events [Bradycardia, Tachycardia], Step Count, Movement [VMU], Recording Time, Analysis Time

6-minute walk test parameters:
O2-Gap, Estimated Distance, Distance Traveled, Theoretical Distance [Min, Standard], TΔ2% [SpO2≥2%], TΔ4% [ΔSpO2≥4%], Time [Rest, Walk, Recovery], Desaturation Area/Distance, Borg Dyspnea [Onset, End, Diff.], Borg Fatigue [Onset, End, Diff.], Blood Pressure [Systolic, Diastolic], Oxygen Delivered

Sleep oximetry parameters:
Body Position, SpO2 Events, Desaturation Index (ODI), Desaturation [Value, Duration, Nadir], ΔSpO2 [Min Drop, Max Drop], Pulse Variation, Pulse Index, NOD89% [SpO2<89%; >5min], NOD4% [SpO2 Baseline-4%; >5min], NOD90% [SpO2<90%; Nadir<86%; >5min]

TECHNICAL SUPPORT:
We are an authorized MIR service center, so if you experience any problems or breakdowns, whether within or outside the warranty period, you can contact us directly by calling 0105761476.

Equipment:
- Pulse oximeter
- Transport bag
- Soft Adult Sensor
- Power supply
- USB cable
- MIR Spiro Software
