MIXING 2 EVO - Combined electrotherapy + ultrasound therapy - 2 channels

MIXING 2 is an electrotherapy stimulator with a built-in ultrasound unit. It is equipped with two independent stimulation channels with adjustable intensity for delivering low- and medium-frequency treatments. The ultrasound unit operates at a frequency of 1MHz. Ultrasound can operate independently or in combination with either of the two stimulator channels.

PATIENT DATABASE allows you to store:
- patient details
- pathology
- treatment description
- treatment customization
- assessment of pain level at the beginning and end of treatment. Our patient database provides immediate access to personalized treatment, allowing it to be repeated quickly and easily.

PROGRAMS AND SEQUENCES
Large memory for storing new programs and sequences of combined programs. This allows you to create personalized treatments tailored to the patient's specific needs.

STIMULATION MODES:
TENS: features many built-in programs for the most common conditions. Frequency: 2÷200Hz. Pulse duration: 50÷600 µs. Intensity: 0÷250 mA (Ipp).
Muscle: symmetrical bidirectional pulses. Includes a file containing a series of programs for treating various muscular conditions. Frequency: 2÷200Hz. Duration: 50÷600 µs. Intensity: 0÷250mA (Ipp).
Bipolar interferential current: bidirectional square-wave current, amplitude-modulated. Square-wave frequency: 4000Hz. (±20%) Sinusoidal modulation frequency: 5÷200Hz. Intensity: 0÷250mA (Ipp).
Tetrapolar vector: bidirectional, amplitude-modulated current. Square-wave frequency 4000Hz. Sinusoidal modulation frequency 5÷200Hz,
Intensity 0÷250 mA (Ipp)
Kotz: interrupted sinusoidal current. Sinusoidal frequency: 1000÷2500Hz. Modulation frequency: 5÷200Hz. Intensity: 0÷250mA (Ipp).
Faradic current: unidirectional pulses. Frequency: 1÷100Hz. Intensity: 0÷130mA (Ip).
Iontophoresis: interrupted unidirectional current. Frequency: 8000Hz. Duty cycle: 95%. Intensity: 0÷30mA (Ip).
Diadynamic currents: monophasic (MF), biphasic (DF), short period (CP), long period (LP). Intensity: 0÷30mA (Ip).
Pulses: unidirectional rectangular and triangular pulses. Duration: 1÷1000 ms. Pause: 1÷5 s. Intensity: 0÷30 mA
Traebert: rectangular, unidirectional current. Pulse duration: 2 ms. Pause: 5 ms. Intensity: 0÷30 mA
Urology: symmetrical bidirectional pulses. Frequency: 2 ÷ 200 Hz. Pulse duration: 50÷600 µs. Maximum current: 250 mA (Ipp). Output characteristic: constant voltage (CV)

MODES Ultrasound:
Nominal frequency: 1MHz
Number of heads: 1
Pulse frequency: 100Hz
Output: continuous and pulsed
Intensity: 0 ÷ 2W/cm2 continuous
0 ÷ 3W/cm2 pulsed
Sound head: 1MHz, 5 cm2 with visual indication without contact, suitable for underwater treatments
Time: 0 ÷ 30 min

Continuous output with maximum power of 2W/cm²
Pulsed output with maximum power of 3W/cm²
Preset programs for common conditions
Visual and audible indication without contact
Real-time treatment duration (the timer stops in the event of poor contact)
Large graphic display showing all output parameters
Ultrasound unit can be connected to a stimulator channel for combined therapy

Power supply: 115 – 230 V (±10%) 50-60Hz
Input: 80 VA
Weight: 4.2 kg
Dimensions (L × D × H): 33 x 32,8 x 23 cm
Insulation class: Class I – type BF

TECHNICAL DATA Ultrasound:
Nominal frequency: 1MHz
Number of heads: 1
Pulse frequency: 100Hz
Output: continuous and pulsed
Intensity: 0 ÷ 2W/cm2 continuous
0 ÷ 3W/cm2 pulsed
Sound head: 1MHz, 5 cm2 with visual indication without contact, suitable for underwater treatments
Time: 0 ÷ 30 min

Continuous output with maximum power of 2W/cm²
Pulsed output with maximum power of 3W/cm²
Preset programs for common conditions
Visual and audible indication without contact
Real-time treatment duration (the timer stops in the event of poor contact)
Large graphic display showing all output parameters
Ultrasound unit can be connected to a stimulator channel for combined therapy

TECHNICAL DATA Electrotherapy:
11 stimulation modes (current types)
Simple or combined preset treatment protocols
User-programmable protocols for each of the 11 emission modes
Programs belonging to the same output mode can be sequenced
Constant current/constant voltage
Intuitive system
Patient database
Ability to store modified programs and protocol sequences

1 pc. – Sound head 1MHz/5cm2 (A01.00053)
1 pc. – 260 g gel tube (R/273)
2 pcs. – Electrotherapy cables (C/IS)
4 pcs. – 60X40 mm electrodes (EL/1)
2 pcs. – 60X60 mm electrodes (EL/2)
2 pcs. – 60X120 mm electrodes (EL/3)
4 pcs. – Pads for EL/1 (S/1)
2 pcs. – Pads for EL/2 (S/2)
2 pcs. – Pads for EL/3 (S/3)
2 pcs. – Elastic straps 50 cm (F6)
2 pcs. – Elastic straps 100 cm (F7)
1 pc. – Black splitter cables (C/DU-N)
1 pc. – Red splitter cables (C/DU-R)
1 pc. – Black cable with 2 mm plug (C/RD-N)
1 pc. – Red cable with 2 mm plug (C/RD-R)
1 pc. – Power cable (C/A)
