CU-SP1 automatic iPAD defibrillator – GB, FR, IT, ES, PT, DE, NL, GR, US, KR; specify the language when ordering

The iPAD CU-SP1 defibrillator represents the latest generation of devices for public use, designed to offer innovation and ease of use. This Automated External Defibrillator (AED) analyzes the electrocardiogram (ECG) to identify shockable rhythms such as ventricular fibrillation or ventricular tachycardia. If detected, the device charges and automatically delivers an electric shock. Voice prompts and visual indicators guide the user throughout the rescue process.

Technical specifications:
- Mode: Automatic
- Waveform: Truncated exponential biphasic
- Energy: Adult 150 J at 50 ohms, infant/child 50 J at 50 ohms
- Charge control: Automatic patient analysis system
- Charging time: <10 seconds
- Water resistance: IPX5
- Dust protection: IP5X
- Dimensions: 260x256x69,5 mm
- Weight: 2.4 kg

User interface:
- User support: Voice prompts and flashing indicators
- CPR guidance: Voice instructions for CPR on adults and children
- Controls: On/off button, “i” button
- Indicators: LCD display for device, battery and pad status
- Sensors: Expiration date and pad connection status
- CPR monitoring
- Automatic volume adjustment

Data recording and transmission:
- IrDA port for communication with a PC
- Internal memory capacity: 5 individual events / max. 3 hours
- PC software: CU-EX1

Patient analysis system:
- Shockable rhythms: Ventricular fibrillation, tachycardia
- Sensitivity/specificity: Compliant with AAMI DF80

Battery:
- Type: DC 12 volts 4.2 Ah, LiMnO2
- Capacity: At least 200 shocks or 8 hours of operation

Operating altitude range:
- Altitude: 0-4570 m (0-15000 ft)

Included:
- Adult pads
- Carrying case
- Single-use lithium battery
- Printed manual (GB, IT)
- Multilingual manual on CD

The CU-SP1 stands out for its automatic volume adjustment, which adapts to ambient noise, pre-connected pads for rapid use, and a CPR detection system that guides the user in performing cardiopulmonary resuscitation correctly. The CU-EX1 software makes data analysis easy, improving the management and effectiveness of the device.
