The MG WAVE EVO professional medical device is an advanced solution for low-frequency magnetotherapy. Designed for portable use, it uses pulsating electromagnetic fields to offer personalized and effective treatments.

Patient Archive:
- Patient data storage
- Pathology
- Description of the treatment
- Personalization of the treatment
- Assessment of the level of pain at the beginning and end of treatment

The patient database allows immediate access to personalized treatments, facilitating the rapid and precise repetition of therapies.

Programs and sequences:
- Large memory for new programs
- Creation of tailor-made treatments
- High output power
- Simple parameter setting
- Preset programs for common pathologies
- Easy positioning of the reel
- Flat or circular coils for specific treatments
- Large graphic display
- Storage of modified programs and sequences

Specifications:
- Number of outputs: 2
- Field pilot signal: rectangular
- Pulse duration: up to 5 ms
- Frequency: 1 ÷ 750 Hz

Max. Induction B:
- 160 Gauss (Peack) for Ø 15 cm and Ø 7.5 cm reels
- 65 Gauss (Peack) for Ø 30 cm reels
- 50 Gauss (Peack) for Ø 60 cm reels

Timer:
- 0÷240 min.
- Acoustic signal at the end of treatment
- Automatic shutdown

Power supply:
- 115 – 230 Vac, 50 – 60 Hz
- Input: 55 VA

Dimensions:
- Central unit: 27 x 32.8 x 23 cm (WxDxH)
- Flat reels: Ø 15 cm each.

Weight:
- Central unit: 3.8 Kg
- Flat reels: 750 gr. per person

Insulation class:
- Class I – type BF

Equipment:
- 1 pc. – Red cable for 15 cm reels (A01.00077)
- 1 pc. – Black cable for 15 cm reels (A01.00078)
- 1 pc. – Power cord (C/A)
- 2 pieces – 100 cm elastic straps (F7)
- 1 pc. – Magnet (MGN)
- 1 pc. – Reel Ø 15cm (A01.00083)
