ECG, 1-CHANNEL, 100G

- Large LCD display for viewing waveforms and data
- High-resolution matrix thermal printer
- Frequency response: 150 Hz
- Continuous printing of the ECG trace and annotations, including lead, sensitivity, printing speed and filter status
- The high-resolution digital filter prevents baseline drift without altering the ECG waveform
- Floating input circuit compliant with IEC safety standards
- Rechargeable battery (more than 50 examinations per charge)
- Internal software: GB, FR, IT, ES, DE, TR

Manual: GB, FR, IT, ES

1 piece. Safety type: Class I, type CF applied parts (applied parts with defibrillation protection)
Leads: 12 standard
Sampling frequency: 800 Hz
Frequency response: 0,05Hz~150Hz (-3dB, + 0,4dB)
Time constant: = 3,2s
CMRR: >60dB
Noise level: <15µVp-p
EMG interference filter: 35Hz (-3dB)
AC filter: 50Hz/60Hz (-20dB)
Recording mode: Thermal printer
Paper type: 50mm × 20m
Sensitivity: 5, 10, 20mm/mV
Printing speed: Automatic recording: automatic lead switching, Rhythm recording: 25 mm/s, 50 mm/s, Manual recording: 25 mm/s, 50 mm/s
Power supply: AC 110-220V, 50/60 Hz
DC - lithium battery: 7,4V, 2500 mAh
Fuses: 2 pcs. f5×20mm slow-blow AC; T2A/250V (Power supply: 220 V)
Dimensions: 315 x 215 x 77 mm
Net weight: 1.5 kg - ECG cable
- 1 set of clamp limb electrodes
- 1 set of precordial electrodes
- Grounding cable
- Power cable
- Paper roll
