- Fully digital signal management
- Adjustable LCD display shows waveforms
- High resolution thermal printer
- Built-in rechargeable lithium battery, AC/DC power supply
- Fully digital filters, avoids line deviation
base, AC interference, EMG
- Automatically adjustable baseline, printing position
Optimized.
- Selectable operating mode.
- detection of detached electrode.
The 3-channel model also has these features:
- simultaneous acquisition of 12 leads.
- automatic ECG parameters.
- Selectable print formats.
- Support for ink-jet printer.
- USB for printing 12 leads.

Input circuit: Input oscillating circuit, defibrillator and pacemaker protection
Lead: Standard 12 leads
Acquisition mode: 12 simultaneous leads
Time Constant: > 3.2 sec
Accuracy: 2.5, 5, 10, 20, mm/mV
Input Impedance:> 50MΩ
Baseline Deviation: Automatic
Filters: EMG filter 25 Hz/35Hz/off
DFT filter 0.05/0.15 /0.25/0.5Hz
Low pass filter 150Hz/100Hz/75Hz
AC 50 Hz/60Hz filter
CMRR:>100dB
Recording Mode: Auto/Manual/Rhythm
Rhythm Lead: Any lead is selectable
Safety standard: IEC I/CF
Power supply: AC: 100V-115V/220V-240V, 50/60Hz
Rechargeable lithium-ion battery: selectable voltage=14.4V
More than 3 hours of uninterrupted use on battery power
Thermal Printer
Report paper: 5mm/s, 10mm/s, 12.5mm/s, 25mm/s
Size: 288mmx210mmx70mm
Display: LCD 320x240 pixels (Wide screen)
Selectable display language Ita – ing – spa – fra - russo
Interface: RS232, USB

- Patient cable
- 1 bottle of gel
- 1 roll of paper
- 4 peripheral electrodes
- 6 precordial electrodes
-Rechargeable
- Manual: English, French, Spanish, Italian
