Pre-gelled pediatric foam ECG electrodes 32 mm x 36 mm - Ag/AgCl - Pack of 100 electrodes

Pre-gelled pediatric electrodes in adhesive sponge (FOAM) with Ag/AgCl sensor and solid gel.

- Use: Adults
- Connection: clip
- Dimensions: 32 mm X 36 mm (oval)
- Shape: oval

- GEL: Solid hydrogel
- Clip: Steel
- Sensor: Ag-AgCl
- Gel protection film – reinforcement disc: transparent PET
- Support: Medical grade PE FOAM foam material
- Adhesive: Biocompatible synthetic resin
- Sterilization: Non-sterile
- COMPLIANCE WITH REGULATIONS: Directive 93/42/EEC (DL 46/97). Class I device.

ELECTRICAL CHARACTERISTICS (ANSI/AAMI EC12:2000 Specification / Maximum Value)
- Average impedance value measured at 10Hz for 12 pairs of electrodes: 70 Ω
- Single pair impedance: 75 Ω
- Offset Voltage: 2 mV
- Offset instability combined with intrinsic noise: 3 μV
- Residual voltage after defibrillation: 18 mV
- Polarization change: 0.7 mV/s
- Impedance at 10 Hz after testing: 52 Ω
- Bias current tolerance: 16.1 mV
