SEMI-AUTOMATIC DEFIBRILLATOR I-PAD CU-SPR

Voice Software: US, GB, FR, IT, ES, DE, PL, KR, JP, Arabic
CD Manual: US, GB, IT, ES, DE, PL, KR, FR, Arabic

Semi-Automatic External Defibrillator (AED) with public access, advanced and intuitive.
Simple to use, lightweight, portable, for rescue operations on both adults and children.
It automatically reads the patient's electrocardiogram (ECG) and determines if a cardiac arrest has occurred and if defibrillation is required.
The defibrillator has built-in voice commands and graphic LED indicators that guide the rescuer throughout the course of the operation.
The status of the battery and plates can be quickly checked on the LCD screen, so the device is always ready for use.
Being highly waterproof and dustproof, CU-SPR can also be used in humid environments and extreme conditions.

Suitable for public use.

Key features:
- Device and plate status can be quickly checked on the LCD screen
- Metronome, voice guidance, and graphical CPR instructions
- Quick switch button between adult and pediatric modes
- Data transfer via USB with optional flash drive

Tehnology
- automatic defibrillation with truncated exponential biphasic wave
- Combined adult/pediatric plaques
- Automatic background noise analysis and automatic volume adjustment
- CPR phase detection indicator for more effective CPR

Security
- highly waterproof IP66 enclosure
- automatic internal discharge
- daily, weekly and monthly self-testing
- Impact-resistant carrying bag

1 pc. Defibrillator
Operation mode: semi-automatic
Waveform: Truncated Exponential Biphasic)
LCD/LED screen: device status, battery level and plate status
Output energy: 200 J at 50 O adult load / 50 J at 50 O child load
Download control: automatic patient analysis system
Discharge Time: Within 3 seconds of the voice instruction requesting discharge
Time from start of rhythm analysis: 12 seconds with new battery (even after 15 discharges at 200J)
Time from ignition to low availability: 25 seconds with new battery at full charge (even after 15 discharges at maximum energy)
Time from CPR to discharge: at least 6 seconds from the end of CPR to the delivery of the shock
Deactivation:
- the patient's heart rhythm returns non-shockable
- SHOCK button is not pressed within 15 seconds
Speaker: Sounds voice commands
Sound level: 80 ~ 90 dB (±3dB), at 1m from the speaker
Beep: Provides various sound indications
Automatic self-test: Power-on self-test, Execution self-test, Daily, weekly and monthly self-test
Manual test: Battery insertion test
Battery Type: LiMnO2 12V DC, 4.2Ah, Disposable
Operating time: at least 150 discharges (200J) for a new battery or 6 hours of operation
Battery shelf life: at least 5 years from the date of manufacture
Memory: internal: 5 individual treatments, up to 3 hours per treatment
Dimensions - weight: 240x230xh 70 mm - 2 kg

ECG analysis system
Impedance Range: 25O - 175O
Shockable rhythms: ventricular fibrillation or rapid ventricular tachycardia
ECG lead acq.: Lead II
Frequency response: 1 Hz - 30 HzAdult plates
Carrying bag
Disposable lithium battery
Paper manual (GB, IT)
