LifeVent EVO2 is a pressovolumetric pulmonary ventilator intended for ventilation
invasive and non-invasive in patients weighing ≥ 2.5 kg.
It is equipped with both a high-pressure mixer and a low-pressure O2 inlet that
they allow the patient to be accompanied from the hospital to his home.

LifeVent EVO2 allows you to set up to 5 preset programs and display up to 7
monitoring screens (waveforms with spontaneous and/or timed act indication,
parameters of dynamic respiratory mechanics, etc.).
Measure, display, record and generate alarms for SpO2, Heart Rate, FiO2 and
EtCO2 when integrated with the appropriate accessories.
Auto-Trak and AVAPS algorithms provide the right therapeutic support to meet the needs of the
needs of patients with the use of simple passive circuits.
The AVAPS algorithm automatically adapts the support pressure to the patient to ensure
a medium volume of ventilation, while the Auto-Trak improves patient-ventilator synchrony
by adapting to changes in breathing pattern and dynamic compensation
of losses.
The compact design, 8'' touchscreen with smart menu (Quick Start Guide for
all parameters and alarms), the 2 batteries, internal and removable of long duration (about 15 hours), the
make a device reliable, versatile and easy to use.
LifeVent EVO2 is equipped with 2Gb internal memory, built-in Bluetooth, 2 USB ports for importing
and export data and for connecting accessories such as pulse oximeter, capnograph
and is compatible with both single-tube and double-tube circuits.

Inspiratory time
0.3 - 5.0 seconds, limited to preventing an inverse ratio of inspiration to exhalation (I:E)
Increment Time
0, 1, 2, 3, 4, 5, 6
Triggers and loops
Off, Auto-Trak, Sensibitive Auto-Trak and Flow Trigger
Flow trigger sensitivity
0.5 - 9 l/min
Sensible. Flow cycle
10% - 90% of peak flow
Flow
Square, Ramp
FiO2
21% – 100%
Time insp. min/max
0.3 - 3.0 sec
Back-up ventilation
Att. - Disable
Screen size
8" (20.32 cm)
Ingress protection
IP22: Protection against ingress of finger-sized objects and dripping water when tilted at 15 degrees
IEC 60601-1 classification
Type of protection against electric shock: Class II equipment
Degree of protection against electric shock: Type BF applied part
Composition
This device contains neither natural rubber latex nor dried natural rubber.
Expected service life
10 years
Internal storage capacity
2 GB
Operation mode
Continuous
Maximum pressure limited
90 cm H2O
Applied Parts Pulse Oximeter, Breathing Circuit
Components added to the breathing circuit, including: flow sensor, cable
Flow Sensor, Accessory & Cable for CO2
Screenshot to view WAVEFORMS:
In addition to pressure and flow waveforms, numeric values for respiratory rate, tidal volume, and leaks are also displayed.
Touch-screen display for displaying parameters;
Possibility to adjust the parameters when the fan is in operation and stand-by.
System Alarms
Fan does not operate Manut. ventilator required, Obstruction Esp pressure, High inspiratory high pressure, Exhaust flow sensor, External flow sensor sensor sensor, External flow sensor not connected, Inverted external flow sensor, Valve. exhalation. Att. failed, Contr. Lin. Val. exhalation. att., Disconn. press line. pross., Disconconnection. Circuit, Oxygen regulation
Primary Patient Alarms
Inspiratory Pressure 1 - 90 cmH2O, Tidal Volume OFF, 10 - 2000 ml, Ventilation Minute OFF, 0.2 - 30 L/min
Respiratory Rate OFF, 1 - 90 BPM, Circuit Disconnect OFF, 5 - 60 sec, Apnea 5 - 60 sec, No trigger OFF, 0.5 - 15 min. (MPV only)
Fan noise level calculated at CPAP = 10 cm H2O simple circuit
Oxygen
Low Flow: 0 to 30 l/min; 10 psi maximum
High pressure: 280 to 600 kPa (41 to 87 psi)

The sale is subject to request for support from specialized paramedic/medical personnel. For installation, request a quote citing a location where intervenire.Apparecchio cannot be managed without specialized support.
Ask for information if necessary.
